Infrared Rotary Dryer (IRD)

Infrared Rotary Dryer (IRD)

The infrared drum dryer features continuous, gentle tumbling and rapid drying, offering 20% to 50% more energy efficiency than traditional drying methods. It is particularly suitable for granular, flake-like, and other chemical industry products.

Add To Inquiry

Prev Next

The IRD uses advanced infrared technology to quickly heat materials, shorten drying time, and greatly upgrade production efficiency. The design of rotating tumble allows the material to be evenly exposed to high-intensity infrared radiation, allowing the moisture to evaporate quickly and protecting the material from damage or discoloration. Our infrared tumble dryer can dry any material easily and efficiently no matter it is flake or granular, and can achieve the ideal drying effect. It is the best solution for dewatering, dehydration and dehumidification.
The IRD drum dryer is heated by an infrared tube and uses infrared radiation to effectively remove moisture from the material. During the drying process, the drum is used to continuously turn the material to be dried to achieve rapid and even heating. It is suitable for drying and dehydration in a variety of industrial industries.

1. Stable Quality: Provides consistent drying, eliminating quality issues due to uneven moisture content.
2. Space Constraints: Its compact design saves valuable floor space in facilities.
3. Increase Capacity: Increases production efficiency with faster drying cycles.
4. Energy Efficient: Uses infrared heating which is more efficient than traditional methods, ensuring lower energy consumption.
5. Uniform Drying: The rotary motion ensures all parts of the material are evenly exposed to infrared rays.
6. Adjustable Control: Features precision control over temperature and rotation speed for optimal drying conditions.

Food processing | Agriculture/fishery | Chemical industry | Composite materials | Plastic manufacturing process | High temperature sterilization

Improve production efficiency:

Compared with traditional drying, the infrared tumble dryer can heat both the inside and outside of the object and is to be dried more quickly, allowing the water to evaporate fast, shortening the drying time and improving production efficiency.

Solve the problem of insufficient output:

The conveying speed of feeding screw and feed flowrate can be adjusted and controlled to easily achieve continuous production, effectively reduce manpower requirements, improve production efficiency, and maintain the stability of material quality.

Low maintenance costs:

The use of infrared tubes eliminates the need to regularly replace high-cost fuel or steam heating boilers, and greatly reducing the cost of subsequent maintenance of the equipment.

•
•
•
•
•
•
•

Spiral tumble:

It has a first-in, first-out design, which enables the dried objects to be dried effectively and evenly, and the dehydration process can be carried out continuously.

Infrared radiation:

Infrared radiation is one of the core technologies. It can heat materials quickly and evenly, and thus shortening drying time and improving product quality.

High-temperature-resistant protective glass:

The high-temperature-resistant protective glass provides the best protection for the infrared tubes and effectively prevents quality concerns caused by materials adhering to the infrared tubes during the drying process.

Air cooling device:

The air cooling device can help reduce the temperature of the infrared tubes and protect the infrared tube, extending the service life of the infrared tubes.

Customized adjustment:

Customized settings can be made according to customer needs, including drying time, temperature, tumble speed, and feed amount, etc., to ensure that customers' different drying needs are met.

Protective fence:

The equipment is in a high temperature state during the dehydration process. The protective fence is designed to prevent people from touching the equipment and avoid personal injury caused by high temperature.

Anti-fool device:

The dryer is equipped with an emergency stop button, it can immediately warn and shut down the machine when an abnormality occurs, protecting the operational safety of user.

TSHS infrared tumble dryers are capable of drying industrial applications of various sizes and shapes, including granules, flakes, and fibers. The infrared tumble dryers are commonly used in dehydration and sterilization of chemical materials.

• Chemical industry: Electronic components, chemical materials, and polymer resins. For drying chemicals and minerals that are sensitive to heat. The infrared tumble dryers are used for drying powdered chemicals such as calcium carbonate, aluminum oxide, magnesium oxide, and zinc oxide in the chemical industry. It mainly removes moisture from chemical substances so that the next stage of processing can be carried out.
• Textile industry: Post-dye drying of textiles to prevent color run-off. The infrared tumble dryers can perform the drying treatment of cotton, linen, silk, wool, synthetic fibers, and other textiles. It can effectively remove moisture from textiles and improve the quality and aesthetics of textiles.
• Food Processing: For dehydrating fruits, vegetables, beans, konjac and rice and meats.
• Pharmaceuticals: Drying of granulated materials and powders.
• Other industries: Medical devices, rubber materials and plastic products.
